PI Web API Cookbook

import os
import requests

from requests.adapters import HTTPAdapter
from urllib3.util.retry import Retry

def create_pi_session(
    base_url: str | None = None,
    username: str | None = None,
    password: str | None = None,
    ca_bundle: str | bool | None = None,
    pool_size: int = 10,
    max_retries: int = 3,
) -> requests.Session:
    """Create a configured session for PI Web API.

    Args:
        base_url: PI Web API URL (falls back to PI_WEB_API_URL env var)
        username: Auth username (falls back to PI_USERNAME env var)
        password: Auth password (falls back to PI_PASSWORD env var)
        ca_bundle: Path to CA cert, True for default, False to skip verify
        pool_size: Connection pool size (increase for high concurrency)
        max_retries: Number of retries for transient failures
    """
    session = requests.Session()

    # Authentication
    user = username or os.environ.get("PI_USERNAME", "")
    pwd = password or os.environ.get("PI_PASSWORD", "")
    if user:
        session.auth = (user, pwd)

    # SSL verification
    if ca_bundle is not None:
        session.verify = ca_bundle
    else:
        env_bundle = os.environ.get("PI_CA_BUNDLE")
        session.verify = env_bundle if env_bundle else True

    # Connection pooling + retry logic
    retries = Retry(
        total=max_retries,
        backoff_factor=1,  # 1s, 2s, 4s between retries
        status_forcelist=[408, 429, 500, 502, 503, 504],
        allowed_methods=["GET", "HEAD"],  # Only retry safe methods
    )
    adapter = HTTPAdapter(
        max_retries=retries,
        pool_connections=pool_size,
        pool_maxsize=pool_size,
    )
    session.mount("https://", adapter)

    # Default headers
    session.headers.update({
        "Accept": "application/json",
        "Content-Type": "application/json",
        "X-Requested-With": "PiSharp-Cookbook",
    })

    return session


# Usage
BASE_URL = os.environ.get("PI_WEB_API_URL", "https://myserver/piwebapi")
session = create_pi_session()

# Verify connectivity
resp = session.get(f"{BASE_URL}/")
if resp.ok:
    info = resp.json()
    print(f"Connected to {info['ProductTitle']} {info['ProductVersion']}")
else:
    print(f"Connection failed: {resp.status_code}")

def find_point_by_path(session, base_url, server_name, point_name):
    """Find a PI point by its full path. Most reliable method.

    Returns: (web_id, point_name) tuple
    """
    path = f"\\\\{server_name}\\{point_name}"
    resp = session.get(
        f"{base_url}/points",
        params={
            "path": path,
            "selectedFields": "WebId;Name;PointType;EngineeringUnits",
        },
    )
    resp.raise_for_status()
    data = resp.json()
    return data["WebId"], data["Name"]


def find_points_by_filter(session, base_url, data_server_web_id,
                          name_filter, max_count=100):
    """Find PI points by name pattern on a specific data server.

    Args:
        name_filter: Wildcard pattern like "Temperature*" or "Unit1_*"

    Returns: List of {WebId, Name, PointType} dicts
    """
    resp = session.get(
        f"{base_url}/dataservers/{data_server_web_id}/points",
        params={
            "nameFilter": name_filter,
            "maxCount": max_count,
            "selectedFields": "Items.WebId;Items.Name;Items.PointType",
        },
    )
    resp.raise_for_status()
    return resp.json().get("Items", [])


# Usage: path-based lookup (preferred)
web_id, name = find_point_by_path(session, BASE_URL, "MY-PI-SERVER", "sinusoid")
print(f"Found {name}: {web_id}")

# Usage: filter-based lookup (multiple points)
# First get the data server WebID
ds_resp = session.get(f"{BASE_URL}/dataservers",
                      params={"selectedFields": "Items.WebId;Items.Name"})
ds_web_id = ds_resp.json()["Items"][0]["WebId"]

points = find_points_by_filter(session, BASE_URL, ds_web_id, "Temperature*")
for p in points:
    print(f"  {p['Name']}: {p['WebId']}")

def read_current_value(session, base_url, web_id):
    """Read the current snapshot value for a PI point.

    Handles digital states, bad quality, and returns a clean dict.
    """
    resp = session.get(
        f"{base_url}/streams/{web_id}/value",
        params={"selectedFields": "Timestamp;Value;Good;Questionable;Substituted"},
    )
    resp.raise_for_status()
    data = resp.json()

    # Handle digital state values (come as objects, not numbers)
    value = data["Value"]
    is_digital = isinstance(value, dict)
    if is_digital:
        value = value.get("Name", value.get("Value", str(value)))

    return {
        "value": value,
        "timestamp": data["Timestamp"],
        "good": data.get("Good", True),
        "questionable": data.get("Questionable", False),
        "substituted": data.get("Substituted", False),
        "is_digital": is_digital,
    }


# Usage
result = read_current_value(session, BASE_URL, web_id)
if result["good"]:
    print(f"Value: {result['value']} at {result['timestamp']}")
else:
    print(f"Bad quality value: {result['value']} (questionable={result['questionable']})")

import pandas as pd
from datetime import datetime, timedelta, timezone

def recorded_to_dataframe(
    session, base_url, web_id,
    start_time="*-24h", end_time="*",
    max_count=10000, boundary_type="Inside",
    filter_good_only=True,
):
    """Fetch recorded values and return as a pandas DataFrame.

    Args:
        boundary_type: "Inside" (default), "Outside", or "Interpolated"
        filter_good_only: If True, remove bad-quality values

    Returns: DataFrame with Timestamp index, Value column
    """
    resp = session.get(
        f"{base_url}/streams/{web_id}/recorded",
        params={
            "startTime": start_time,
            "endTime": end_time,
            "maxCount": max_count,
            "boundaryType": boundary_type,
            "selectedFields": "Items.Timestamp;Items.Value;Items.Good",
        },
    )
    resp.raise_for_status()
    items = resp.json().get("Items", [])

    if not items:
        return pd.DataFrame(columns=["Value"])

    df = pd.DataFrame(items)
    df["Timestamp"] = pd.to_datetime(df["Timestamp"], utc=True)
    df = df.set_index("Timestamp").sort_index()

    # Handle digital state values
    def extract_value(v):
        if isinstance(v, dict):
            return v.get("Name", v.get("Value"))
        return v

    df["Value"] = df["Value"].apply(extract_value)

    # Filter by quality
    if filter_good_only and "Good" in df.columns:
        df = df[df["Good"] == True]

    # Warn if data was truncated
    if len(items) == max_count:
        print(f"WARNING: Returned exactly {max_count} values. "
              f"Data may be truncated. Increase maxCount or narrow time range.")

    return df[["Value"]]


# Usage
df = recorded_to_dataframe(session, BASE_URL, web_id, start_time="*-48h")
print(f"Got {len(df)} values")
print(df.describe())

def get_summaries(
    session, base_url, web_id,
    start_time="*-24h", end_time="*",
    summary_type="Average,Minimum,Maximum,Count,PercentGood",
    calculation_basis="TimeWeighted",
):
    """Get summary statistics for a PI point.

    Args:
        summary_type: Comma-separated list. Options: Average, Minimum,
            Maximum, Total, Count, StdDev, Range, PercentGood, All
        calculation_basis: "TimeWeighted" (default) or "EventWeighted"
            TimeWeighted: Weights values by duration (correct for flow/rate)
            EventWeighted: Equal weight per event (correct for batch counts)
    """
    resp = session.get(
        f"{base_url}/streams/{web_id}/summary",
        params={
            "startTime": start_time,
            "endTime": end_time,
            "summaryType": summary_type,
            "calculationBasis": calculation_basis,
        },
    )
    resp.raise_for_status()

    results = {}
    for item in resp.json().get("Items", []):
        stat_type = item["Type"]
        value = item["Value"]
        results[stat_type] = {
            "value": value.get("Value"),
            "timestamp": value.get("Timestamp"),
            "good": value.get("Good", True),
        }

    return results


# Usage
stats = get_summaries(session, BASE_URL, web_id, start_time="*-7d")
for stat, data in stats.items():
    print(f"{stat}: {data['value']}")

# Example output:
# Average: 72.34
# Minimum: 65.12
# Maximum: 81.90
# Count: 8640
# PercentGood: 99.87

from datetime import datetime, timezone

def write_value(
    session, base_url, web_id, value, timestamp=None,
    update_option="Replace", buffer_option="BufferIfPossible",
):
    """Write a single value to a PI point.

    Args:
        update_option: "Replace", "Insert", "NoReplace", "Remove",
                       "InsertNoCompression"
        buffer_option: "BufferIfPossible", "Buffer", "DoNotBuffer"
            BufferIfPossible: Queue if Data Archive is temporarily unavailable
            DoNotBuffer: Fail immediately if Data Archive is down

    Returns: True if write succeeded
    """
    if timestamp is None:
        timestamp = datetime.now(timezone.utc).isoformat()

    resp = session.post(
        f"{base_url}/streams/{web_id}/value",
        json={"Value": value, "Timestamp": timestamp},
        params={
            "updateOption": update_option,
            "bufferOption": buffer_option,
        },
    )

    if resp.status_code in (200, 202, 204):
        return True

    # Parse error details
    try:
        errors = resp.json().get("Errors", [])
        print(f"Write failed ({resp.status_code}): {errors}")
    except Exception:
        print(f"Write failed ({resp.status_code}): {resp.text[:200]}")

    return False


# Usage
success = write_value(session, BASE_URL, web_id, 72.5)
print(f"Write {'succeeded' if success else 'failed'}")

def write_values(session, base_url, web_id, values,
                 update_option="Replace"):
    """Write multiple values to a PI point.

    Args:
        values: List of {"Value": ..., "Timestamp": ...} dicts

    Returns: (success_count, error_count) tuple
    """
    resp = session.post(
        f"{base_url}/streams/{web_id}/recorded",
        json=values,
        params={"updateOption": update_option},
    )

    if resp.status_code in (200, 202, 204):
        return len(values), 0

    # Check for partial failures
    if resp.status_code == 207:  # Multi-status
        body = resp.json()
        errors = [e for e in body.get("Errors", []) if e]
        return len(values) - len(errors), len(errors)

    print(f"Write failed ({resp.status_code}): {resp.text[:300]}")
    return 0, len(values)


# Usage
values = [
    {"Value": 70.1, "Timestamp": "2026-03-15T10:00:00Z"},
    {"Value": 71.3, "Timestamp": "2026-03-15T10:05:00Z"},
    {"Value": 72.0, "Timestamp": "2026-03-15T10:10:00Z"},
    {"Value": 73.5, "Timestamp": "2026-03-15T10:15:00Z"},
]
ok, err = write_values(session, BASE_URL, web_id, values)
print(f"Written: {ok} succeeded, {err} failed")

def batch_read_current(session, base_url, web_ids, chunk_size=100):
    """Read current values for many points using chunked batch requests.

    Args:
        web_ids: List of (name, web_id) tuples or just web_id strings
        chunk_size: Max sub-requests per batch (100 is a safe default)

    Returns: Dict mapping name/index to {value, timestamp, good}
    """
    # Normalize input
    if web_ids and isinstance(web_ids[0], str):
        web_ids = [(f"point_{i}", wid) for i, wid in enumerate(web_ids)]

    all_results = {}

    for i in range(0, len(web_ids), chunk_size):
        chunk = web_ids[i : i + chunk_size]
        batch = {}
        for name, wid in chunk:
            batch[name] = {
                "Method": "GET",
                "Resource": (
                    f"{base_url}/streams/{wid}/value"
                    f"?selectedFields=Timestamp;Value;Good"
                ),
            }

        resp = session.post(f"{base_url}/batch", json=batch)
        resp.raise_for_status()

        for key, result in resp.json().items():
            if result["Status"] == 200:
                content = result["Content"]
                value = content["Value"]
                if isinstance(value, dict):
                    value = value.get("Name", value.get("Value"))
                all_results[key] = {
                    "value": value,
                    "timestamp": content["Timestamp"],
                    "good": content.get("Good", True),
                }
            else:
                all_results[key] = {
                    "value": None,
                    "error": result["Status"],
                }

    return all_results


# Usage
point_list = [
    ("Temperature", "F1DPaH..."),
    ("Pressure", "F1DPbX..."),
    ("Flow", "F1DPcY..."),
]
values = batch_read_current(session, BASE_URL, point_list)
for name, val in values.items():
    if "error" not in val:
        print(f"{name}: {val['value']}")
    else:
        print(f"{name}: ERROR {val['error']}")

def get_af_databases(session, base_url):
    """List all AF databases."""
    resp = session.get(f"{base_url}/assetservers")
    resp.raise_for_status()
    servers = resp.json().get("Items", [])

    databases = []
    for server in servers:
        resp = session.get(
            f"{base_url}/assetservers/{server['WebId']}/assetdatabases",
            params={"selectedFields": "Items.WebId;Items.Name"},
        )
        if resp.ok:
            databases.extend(resp.json().get("Items", []))
    return databases


def get_child_elements(session, base_url, parent_web_id, max_count=1000):
    """Get child elements of an AF element."""
    resp = session.get(
        f"{base_url}/elements/{parent_web_id}/elements",
        params={
            "maxCount": max_count,
            "selectedFields": "Items.WebId;Items.Name;Items.TemplateName;Items.HasChildren",
        },
    )
    resp.raise_for_status()
    return resp.json().get("Items", [])


def get_element_attributes(session, base_url, element_web_id):
    """Get all attributes and their current values for an element."""
    resp = session.get(
        f"{base_url}/elements/{element_web_id}/attributes",
        params={
            "selectedFields": "Items.WebId;Items.Name;Items.Value;Items.Type",
        },
    )
    resp.raise_for_status()
    return resp.json().get("Items", [])


def walk_af_tree(session, base_url, element_web_id, depth=0, max_depth=3):
    """Recursively walk the AF hierarchy and print the tree."""
    children = get_child_elements(session, base_url, element_web_id)
    for child in children:
        indent = "  " * depth
        template = child.get("TemplateName", "")
        suffix = f" [{template}]" if template else ""
        print(f"{indent}{child['Name']}{suffix}")

        if child.get("HasChildren") and depth < max_depth:
            walk_af_tree(session, base_url, child["WebId"],
                         depth + 1, max_depth)


# Usage
# List databases
dbs = get_af_databases(session, BASE_URL)
for db in dbs:
    print(f"Database: {db['Name']}")

# Walk the tree from the database root
if dbs:
    # Get root elements of first database
    resp = session.get(
        f"{BASE_URL}/assetdatabases/{dbs[0]['WebId']}/elements",
        params={"selectedFields": "Items.WebId;Items.Name;Items.HasChildren"},
    )
    roots = resp.json().get("Items", [])
    for root in roots:
        print(f"\n{root['Name']}")
        walk_af_tree(session, BASE_URL, root["WebId"])

def search_event_frames(session, base_url, database_web_id,
                        start_time="*-7d", end_time="*",
                        template_name=None, name_filter=None,
                        max_count=100):
    """Search for event frames in an AF database."""
    params = {
        "startTime": start_time,
        "endTime": end_time,
        "maxCount": max_count,
        "searchMode": "Overlapping",
        "selectedFields": (
            "Items.WebId;Items.Name;Items.TemplateName;"
            "Items.StartTime;Items.EndTime"
        ),
    }
    if template_name:
        params["templateName"] = template_name
    if name_filter:
        params["nameFilter"] = name_filter

    resp = session.get(
        f"{base_url}/assetdatabases/{database_web_id}/eventframes",
        params=params,
    )
    resp.raise_for_status()
    return resp.json().get("Items", [])


def create_event_frame(session, base_url, element_web_id,
                       name, start_time, end_time=None,
                       template_name=None, description=None):
    """Create a new event frame on an AF element.

    If end_time is None, creates an open (in-progress) event frame.
    """
    payload = {
        "Name": name,
        "StartTime": start_time,
    }
    if end_time:
        payload["EndTime"] = end_time
    if template_name:
        payload["TemplateName"] = template_name
    if description:
        payload["Description"] = description

    resp = session.post(
        f"{base_url}/elements/{element_web_id}/eventframes",
        json=payload,
    )
    resp.raise_for_status()
    # Location header contains the URL of the created event frame
    return resp.headers.get("Location", "")


# Usage: search for recent event frames
frames = search_event_frames(session, BASE_URL, db_web_id,
                             template_name="Batch")
for ef in frames:
    print(f"{ef['Name']}: {ef['StartTime']} -> {ef.get('EndTime', 'In progress')}")

# Usage: create a new event frame
location = create_event_frame(
    session, BASE_URL, element_web_id,
    name="Batch-2026-0315-001",
    start_time="2026-03-15T08:00:00Z",
    end_time="2026-03-15T16:00:00Z",
    template_name="Batch",
    description="Morning production batch",
)
print(f"Created event frame at: {location}")

import json
from pathlib import Path
from datetime import datetime, timezone

class WatermarkTracker:
    """Track extraction watermarks for incremental ETL.

    Stores the last successfully extracted timestamp per point
    so the next run picks up where the previous one left off.
    """

    def __init__(self, path: str = "watermarks.json"):
        self.path = Path(path)
        self.marks = {}
        if self.path.exists():
            self.marks = json.loads(self.path.read_text())

    def get(self, key: str, default: str = "*-24h") -> str:
        return self.marks.get(key, default)

    def set(self, key: str, timestamp: str):
        self.marks[key] = timestamp
        self.path.write_text(json.dumps(self.marks, indent=2))


def incremental_extract(session, base_url, web_id, point_name,
                        tracker, max_count=10000):
    """Extract new recorded values since the last watermark.

    Returns: DataFrame of new values (empty if none)
    """
    import pandas as pd

    start = tracker.get(point_name)
    end = "*"

    resp = session.get(
        f"{base_url}/streams/{web_id}/recorded",
        params={
            "startTime": start,
            "endTime": end,
            "maxCount": max_count,
            "boundaryType": "Outside",
            "selectedFields": "Items.Timestamp;Items.Value;Items.Good",
        },
    )
    resp.raise_for_status()
    items = resp.json().get("Items", [])

    if not items:
        return pd.DataFrame()

    df = pd.DataFrame(items)
    df["Timestamp"] = pd.to_datetime(df["Timestamp"], utc=True)

    # Update watermark to the latest timestamp
    latest = df["Timestamp"].max().isoformat()
    tracker.set(point_name, latest)

    return df.set_index("Timestamp").sort_index()


# Usage
tracker = WatermarkTracker("my_pipeline_watermarks.json")

points = [
    ("Temperature", temp_web_id),
    ("Pressure", pressure_web_id),
]

for name, wid in points:
    df = incremental_extract(session, BASE_URL, wid, name, tracker)
    if not df.empty:
        print(f"{name}: extracted {len(df)} new values")
        # Save to your destination (database, CSV, data lake, etc.)
        # df.to_csv(f"{name}_extract.csv", mode="a", header=False)
    else:
        print(f"{name}: no new data")

from datetime import datetime, timezone, timedelta

def pi_health_check(session, base_url, watchlist_web_ids=None,
                    stale_threshold_minutes=30):
    """Check PI Web API health and data freshness.

    Args:
        watchlist_web_ids: Optional list of (name, web_id) to check freshness
        stale_threshold_minutes: Flag data older than this as stale

    Returns: dict with status, latency, and details
    """
    import time
    result = {"status": "healthy", "checks": {}}

    # Check 1: API reachability
    start = time.perf_counter()
    try:
        resp = session.get(f"{base_url}/", timeout=10)
        latency = time.perf_counter() - start
        result["checks"]["api"] = {
            "status": "ok" if resp.ok else "error",
            "latency_ms": round(latency * 1000),
            "status_code": resp.status_code,
        }
        if not resp.ok:
            result["status"] = "degraded"
    except Exception as e:
        result["checks"]["api"] = {"status": "error", "error": str(e)}
        result["status"] = "down"
        return result

    # Check 2: Data server connectivity
    resp = session.get(f"{base_url}/dataservers",
                       params={"selectedFields": "Items.Name;Items.IsConnected"})
    if resp.ok:
        servers = resp.json().get("Items", [])
        disconnected = [s["Name"] for s in servers if not s.get("IsConnected")]
        result["checks"]["data_servers"] = {
            "status": "ok" if not disconnected else "error",
            "total": len(servers),
            "disconnected": disconnected,
        }
        if disconnected:
            result["status"] = "degraded"

    # Check 3: Data freshness (optional watchlist)
    if watchlist_web_ids:
        stale = []
        threshold = datetime.now(timezone.utc) - timedelta(
            minutes=stale_threshold_minutes
        )
        for name, wid in watchlist_web_ids:
            try:
                resp = session.get(
                    f"{base_url}/streams/{wid}/value",
                    params={"selectedFields": "Timestamp"},
                    timeout=5,
                )
                if resp.ok:
                    ts = datetime.fromisoformat(
                        resp.json()["Timestamp"].replace("Z", "+00:00")
                    )
                    if ts < threshold:
                        stale.append({"name": name, "last_update": ts.isoformat()})
            except Exception:
                stale.append({"name": name, "error": "read failed"})

        result["checks"]["data_freshness"] = {
            "status": "ok" if not stale else "warning",
            "stale_points": stale,
            "threshold_minutes": stale_threshold_minutes,
        }
        if stale:
            result["status"] = "warning" if result["status"] == "healthy" else result["status"]

    return result


# Usage
health = pi_health_check(session, BASE_URL, watchlist_web_ids=[
    ("Reactor_Temp", reactor_temp_wid),
    ("Feed_Flow", feed_flow_wid),
])
print(f"Overall status: {health['status']}")
for check, details in health["checks"].items():
    print(f"  {check}: {details['status']}")
