WebID & Lookup
Every resource in PI Web API is identified by a WebID -- an opaque, URL-safe string that encodes the resource type, server, and identity. This guide explains the WebID format, all lookup methods (path, search, name filter), AF vs PI point differences, caching strategies, and bulk resolution patterns.
What is a WebID?
A WebID is a URL-safe, base64-encoded identifier assigned to every PI resource: points, elements, attributes, servers, databases, and more. You need a resource's WebID to read or write its data via the streaming endpoints.
WebIDs are stable across requests but may change if the underlying object is deleted and recreated, or if the PI Data Archive is migrated. Always look up WebIDs by path or search rather than hardcoding them.
# A typical PI point WebID looks like this:
P1DP9We5Y6kuE07EDQR39tVQ2wQQAAAAUElTUlYwMlxTSU5VU09JRA
# Breaking it down:
# P1 = WebID type prefix (PI Point, encoding type 1)
# DP9We5Y6kuE07EDQR39tVQ2w = encoded server GUID
# QQAAAAUBJUVJ... = encoded point identityWebID type prefixes
The first two characters of a WebID tell you what type of resource it represents and which encoding was used. This is essential for debugging -- if you have a WebID, you can immediately tell what kind of object it refers to.
| Prefix | Resource type | Example context |
|---|---|---|
P1 | PI Point (by GUID) | Individual tag on a PI Data Archive |
I1 | PI Point (by ID) | Point referenced by integer point ID |
F1 | AF Element | Element in an AF hierarchy |
Ab | AF Attribute | Attribute on an AF element |
RD | AF Database | Top-level AF database |
S1 | PI Data Server | PI Data Archive instance |
RS | AF Server | PI AF Server instance |
Fm | AF Event Frame | Event frame in AF |
ET | AF Element Template | Template for creating elements |
Quick debugging trick
If a batch request fails with 404 on a WebID, check the prefix. A P1 prefix means it's a PI point -- pass it to /points/{webId}. An F1 prefix means it's an AF element -- pass it to /elements/{webId}. Using the wrong endpoint for the resource type gives a 404 even if the WebID is valid.
AF elements vs PI points
Understanding the difference between AF elements and PI points is fundamental to working with WebIDs correctly.
| Concept | PI Point | AF Element |
|---|---|---|
| What it is | A single time-series data tag on a PI Data Archive | A logical object in an AF hierarchy (e.g., a pump, reactor, building) |
| Has values? | Yes, directly | No -- its attributes have values (which may reference PI points) |
| Read data via | /streams/{pointWebId}/value | /streams/{attributeWebId}/value |
| Lookup endpoint | /points?path=\\\\SERVER\\tagname | /elements?path=\\\\AF\\DB\\Element |
| WebID prefix | P1 | F1 (element), Ab (attribute) |
Common mistake: reading values from an AF element WebID
You cannot read values directly from an AF element (F1 prefix). You must first get its attributes, then read values from the attribute WebIDs (Ab prefix). Passing an element WebID to /streams/{webId}/value returns a 400 Bad Request.
Look up by path (recommended)
Path-based lookup is the most reliable method. It does not require PI Indexed Search to be configured and works on every PI Web API installation.
PI point by path
# Look up a PI point by its full path
response = session.get(
f"{BASE_URL}/points",
params={
"path": "\\\\YOUR-SERVER\\sinusoid",
"selectedFields": "WebId;Name;PointType;PointClass;Descriptor",
},
)
response.raise_for_status()
point = response.json()
print(f"Name: {point['Name']}")
print(f"WebID: {point['WebId']}")
print(f"Type: {point['PointType']}")
print(f"Class: {point['PointClass']}")
print(f"Descriptor: {point.get('Descriptor', '')}")Expected response:
{
"WebId": "P1DP9We5Y6kuE07EDQR39tVQ2wQQ...",
"Name": "sinusoid",
"PointType": "Float32",
"PointClass": "classic",
"Descriptor": "12 hour sine wave"
}AF element by path
# Look up an AF element by its hierarchy path
response = session.get(
f"{BASE_URL}/elements",
params={
"path": "\\\\YOUR-AF-SERVER\\Database\\Plant1\\Reactor01",
"selectedFields": "WebId;Name;TemplateName;HasChildren;Links",
},
)
response.raise_for_status()
element = response.json()
print(f"Name: {element['Name']}")
print(f"WebID: {element['WebId']}")
print(f"Template: {element.get('TemplateName', 'None')}")AF attribute by path
# Look up an AF attribute by path (element path + pipe + attribute name)
response = session.get(
f"{BASE_URL}/attributes",
params={
"path": "\\\\YOUR-AF-SERVER\\Database\\Plant1\\Reactor01|Temperature",
"selectedFields": "WebId;Name;Type;DefaultUnitsName;DataReferencePlugIn",
},
)
response.raise_for_status()
attribute = response.json()
print(f"Name: {attribute['Name']}")
print(f"WebID: {attribute['WebId']}")
print(f"Value type: {attribute['Type']}")
print(f"Units: {attribute.get('DefaultUnitsName', 'None')}")
print(f"Data ref: {attribute.get('DataReferencePlugIn', 'None')}")
# Now you can read values using this attribute's WebID
values = session.get(
f"{BASE_URL}/streams/{attribute['WebId']}/value",
params={"selectedFields": "Timestamp;Value;Good"},
)
print(f"Current value: {values.json()['Value']}")Path separator reference
PI paths use backslashes (\\). In Python strings, escape them as \\\\ or use raw strings: r"\\\\SERVER\\sinusoid". AF paths separate the element path from the attribute name with a pipe character (|). Nested attributes use additional pipes: Element|Attribute|SubAttribute.
Look up by search
The search endpoint uses PI Indexed Search (must be enabled on the server). It supports rich query syntax with field-specific filters.
Indexed Search must be configured
The /search/query endpoint requires PI Indexed Search to be installed and configured with crawling enabled on the PI Web API server. If Indexed Search is not available, you will get a 502 Bad Gateway or empty results. Use path-based lookup as a more reliable alternative.
# Basic name search
response = session.get(
f"{BASE_URL}/search/query",
params={
"q": "name:sinusoid",
"count": 10,
"selectedFields": "Items.Name;Items.WebId;Items.ItemType;Items.Links",
},
)
response.raise_for_status()
data = response.json()
print(f"Total hits: {data.get('TotalHits', 'unknown')}")
for item in data["Items"]:
print(f" {item['Name']} ({item['ItemType']}) - {item['WebId']}")Search query syntax
| Query | What it finds |
|---|---|
name:temperature* | Points/attributes whose name starts with "temperature" |
name:*flow* AND name:*rate* | Names containing both "flow" and "rate" |
description:"reactor temperature" | Resources with exact phrase in description |
afCategory:"Process Data" | AF elements/attributes in a specific category |
attributeName:Temperature | AF elements that have an attribute named "Temperature" |
name:sin* NOT name:sinusoidu | Names starting with "sin" but excluding "sinusoidu" |
# Scoped search: only points on a specific server
response = session.get(
f"{BASE_URL}/search/query",
params={
"q": "name:*temperature*",
"count": 50,
"scope": "pi:YOUR-DATA-SERVER", # Limit to specific PI Data Archive
"selectedFields": "Items.Name;Items.WebId;Items.ItemType",
},
)
# AF-scoped search: only within a specific AF database
response = session.get(
f"{BASE_URL}/search/query",
params={
"q": "name:*reactor* AND afCategory:Equipment",
"count": 50,
"scope": "af:\\\\YOUR-AF-SERVER\\YourDatabase",
"selectedFields": "Items.Name;Items.WebId;Items.ItemType",
},
)Look up by name filter
When you know the PI Data Archive server but not the exact point name, use the nameFilter parameter on the data server points endpoint. This does not require Indexed Search.
# First, get the data server WebID
servers_resp = session.get(
f"{BASE_URL}/dataservers",
params={"selectedFields": "Items.WebId;Items.Name"},
)
servers = servers_resp.json()["Items"]
# Find your server
server = next(s for s in servers if s["Name"] == "YOUR-SERVER")
server_web_id = server["WebId"]
# List points with a name filter (supports wildcards)
response = session.get(
f"{BASE_URL}/dataservers/{server_web_id}/points",
params={
"nameFilter": "reactor_*_temperature", # Wildcard pattern
"maxCount": 200,
"selectedFields": "Items.WebId;Items.Name;Items.PointType;Items.Descriptor",
},
)
response.raise_for_status()
points = response.json()["Items"]
print(f"Found {len(points)} matching points:")
for point in points:
print(f" {point['Name']} ({point['PointType']}) - {point['WebId']}")AF element hierarchy traversal
AF organizes assets in a tree hierarchy (e.g., Site > Area > Unit > Equipment). You can walk the tree starting from any element.
def get_element_tree(
session, base_url: str, element_web_id: str, depth: int = 0, max_depth: int = 3
) -> dict:
"""Recursively traverse the AF element hierarchy.
Returns a nested dict with element name, WebID, attributes, and children.
"""
# Get element details
element = session.get(
f"{base_url}/elements/{element_web_id}",
params={"selectedFields": "WebId;Name;TemplateName;HasChildren;Links"},
).json()
node = {
"name": element["Name"],
"web_id": element["WebId"],
"template": element.get("TemplateName", ""),
"attributes": [],
"children": [],
}
# Get attributes for this element
attrs_resp = session.get(
f"{base_url}/elements/{element_web_id}/attributes",
params={
"selectedFields": "Items.WebId;Items.Name;Items.Type;Items.DefaultUnitsName",
"maxCount": 200,
},
)
if attrs_resp.status_code == 200:
node["attributes"] = [
{
"name": a["Name"],
"web_id": a["WebId"],
"type": a["Type"],
"units": a.get("DefaultUnitsName", ""),
}
for a in attrs_resp.json().get("Items", [])
]
# Recurse into children if not at max depth
if element.get("HasChildren") and depth < max_depth:
children_resp = session.get(
f"{base_url}/elements/{element_web_id}/elements",
params={
"selectedFields": "Items.WebId;Items.Name;Items.HasChildren",
"maxCount": 500,
},
)
if children_resp.status_code == 200:
for child in children_resp.json().get("Items", []):
child_node = get_element_tree(
session, base_url, child["WebId"], depth + 1, max_depth
)
node["children"].append(child_node)
return node
# Usage: traverse from a root element
root_web_id = "F1..." # Your root element WebID
tree = get_element_tree(session, BASE_URL, root_web_id, max_depth=2)
# Print the tree
def print_tree(node, indent=0):
prefix = " " * indent
template = f" [{node['template']}]" if node['template'] else ""
print(f"{prefix}{node['name']}{template}")
for attr in node["attributes"]:
units = f" ({attr['units']})" if attr['units'] else ""
print(f"{prefix} |-- {attr['name']}: {attr['type']}{units}")
for child in node["children"]:
print_tree(child, indent + 1)
print_tree(tree)Bulk WebID resolution
When you need to look up many resources at once (e.g., 200 PI points by path), use the batch endpoint instead of making 200 individual lookup calls.
def resolve_webids_batch(
session, base_url: str, point_paths: list[str]
) -> dict[str, str]:
"""Resolve multiple PI point paths to WebIDs in one batch call.
Args:
point_paths: List of full PI point paths
(e.g., ["\\\\SERVER\\tag1", "\\\\SERVER\\tag2"])
Returns:
Dict mapping path -> WebID (only successful lookups)
"""
batch = {}
for i, path in enumerate(point_paths):
batch[f"lookup_{i}"] = {
"Method": "GET",
"Resource": (
f"{base_url}/points"
f"?path={path}"
f"&selectedFields=WebId;Name"
),
}
response = session.post(f"{base_url}/batch", json=batch)
response.raise_for_status()
path_to_webid = {}
results = response.json()
for i, path in enumerate(point_paths):
result = results.get(f"lookup_{i}", {})
if result.get("Status") == 200:
path_to_webid[path] = result["Content"]["WebId"]
else:
print(f"Failed to resolve: {path} (HTTP {result.get('Status')})")
return path_to_webid
# Usage: resolve 100 point paths in one HTTP call
paths = [
"\\\\MY-SERVER\\reactor01_temperature",
"\\\\MY-SERVER\\reactor01_pressure",
"\\\\MY-SERVER\\reactor01_flow",
# ... up to hundreds
]
webid_map = resolve_webids_batch(session, BASE_URL, paths)
print(f"Resolved {len(webid_map)} of {len(paths)} paths")WebID caching strategies
WebID lookups add latency to every operation. Since WebIDs are stable (they only change if the resource is deleted and recreated), you should cache them.
import json
from pathlib import Path
class WebIdCache:
"""Simple file-backed WebID cache.
WebIDs are stable identifiers -- they only change if the underlying
object is deleted and recreated. Caching them avoids repeated lookups.
"""
def __init__(self, cache_file: str = "webid_cache.json"):
self.cache_file = Path(cache_file)
self.cache: dict[str, str] = {}
self._load()
def _load(self):
if self.cache_file.exists():
self.cache = json.loads(self.cache_file.read_text())
def _save(self):
self.cache_file.write_text(json.dumps(self.cache, indent=2))
def get(self, path: str) -> str | None:
return self.cache.get(path)
def set(self, path: str, web_id: str):
self.cache[path] = web_id
self._save()
def resolve(self, session, base_url: str, path: str) -> str:
"""Get WebID from cache, or look up and cache it."""
cached = self.get(path)
if cached:
return cached
response = session.get(
f"{base_url}/points",
params={"path": path, "selectedFields": "WebId"},
)
response.raise_for_status()
web_id = response.json()["WebId"]
self.set(path, web_id)
return web_id
def resolve_many(self, session, base_url: str, paths: list[str]) -> dict[str, str]:
"""Resolve multiple paths, using cache where possible."""
result = {}
uncached = []
for path in paths:
cached = self.get(path)
if cached:
result[path] = cached
else:
uncached.append(path)
if uncached:
# Batch-resolve uncached paths
batch = {}
for i, path in enumerate(uncached):
batch[f"lookup_{i}"] = {
"Method": "GET",
"Resource": f"{base_url}/points?path={path}&selectedFields=WebId",
}
resp = session.post(f"{base_url}/batch", json=batch)
resp.raise_for_status()
for i, path in enumerate(uncached):
r = resp.json().get(f"lookup_{i}", {})
if r.get("Status") == 200:
web_id = r["Content"]["WebId"]
self.set(path, web_id)
result[path] = web_id
return result
# Usage
cache = WebIdCache("my_project_webids.json")
# First call: HTTP lookup + cache
web_id = cache.resolve(session, BASE_URL, "\\\\MY-SERVER\\sinusoid")
# Second call: instant cache hit
web_id = cache.resolve(session, BASE_URL, "\\\\MY-SERVER\\sinusoid")When to invalidate the cache
Invalidate cached WebIDs when: (1) a lookup using a cached WebID returns 404, (2) points have been deleted and recreated, or (3) a PI Data Archive has been migrated. For most stable environments, the cache can live indefinitely. Add a try/except around reads that clears the cache entry on 404 and retries the lookup.
WebID 2.0 encoding and decoding
WebID 2.0 allows you to construct a WebID from a known path without making an HTTP lookup call. This is an advanced optimization for high-throughput scenarios where you want to eliminate lookup latency entirely. The webIdType query parameter controls which encoding the server uses in responses.
import base64
import struct
def decode_webid_type(web_id: str) -> dict:
"""Decode the type information from a WebID string.
This extracts the resource type and encoding type from the
first few characters without making any HTTP calls.
"""
# Known type prefixes
TYPE_MAP = {
"P1": "PI Point (GUID)",
"I1": "PI Point (ID)",
"F1": "AF Element",
"Ab": "AF Attribute",
"RD": "AF Database",
"S1": "PI Data Server",
"RS": "AF Server",
"Fm": "AF Event Frame",
"ET": "AF Element Template",
}
prefix = web_id[:2]
resource_type = TYPE_MAP.get(prefix, f"Unknown ({prefix})")
return {
"prefix": prefix,
"resource_type": resource_type,
"full_webid": web_id,
}
# Useful for debugging: what kind of resource is this WebID?
info = decode_webid_type("P1DP9We5Y6kuE07EDQR39tVQ2wQQ...")
print(f"Type: {info['resource_type']}") # PI Point (GUID)
info = decode_webid_type("F1EmAbcDeFgHiJkLmNoPqRsTuV...")
print(f"Type: {info['resource_type']}") # AF Element
# Request WebID 2.0 encoding in API responses
response = session.get(
f"{BASE_URL}/points",
params={
"path": "\\\\MY-SERVER\\sinusoid",
"webIdType": "PathOnly", # or "Full", "IDOnly"
"selectedFields": "WebId;Name",
},
)
# PathOnly WebIDs encode the server and point path, making them
# reconstructible without a lookupLookup method comparison
| Method | Requires | Best for | Limitations |
|---|---|---|---|
| Path lookup | Know exact path | Reliable, works everywhere | Must know the full path |
| Search query | Indexed Search enabled | Flexible queries, partial names | Requires server configuration |
| Name filter | Know the server | Wildcard patterns, no Indexed Search needed | Only PI points, not AF resources |
| Batch resolution | Know paths (many at once) | Bulk lookups, one HTTP call | Subject to batch size limits |
| WebID 2.0 construction | Know path + server GUID | Zero-latency lookups | Complex to implement, fragile |
